3. Projecting an Image (Basic Operation)
❸ Adjusting the Picture Size and Position
Use the adjustable tilt foot, the zoom lever or the focus ring to adjust the picture size and position.
In this chapter drawings and cables are omitted for clarity.
Adjusting the throw angle (the height of an image)
[Tilt foot] (→ page 24)
Adjusting the left and right tilt of an image
[Rear foot] (→ page 24)
Finely adjusting the size of an image
[Zoom lever] (→ page 25)
Adjusting the focus
[Focus ring] (→ page 25)
Adjusting the keystone correction [KEYSTONE] (→ page 26)
