E-25
Menu windows or dialog boxes typically have the following elements:
Title .................... Indicates the menu title.
Highlight ............. Indicates the selected menu or item.
Source ................ Indicates the currently selected source.
Solid triangle ...... Indicates further choices are available. A highlighted
triangle indicates the item is active.
Ta b ..................... Indicates a group of features in a dialog box. Select-
ing on any tab brings its page to the front.
Radio button ....... Use this round button to select an option in a dialog
box.
Check mark ........ Indicates the item is selected.
Slide bar ............. Indicates settings or the direction of adjustment.
Key symbol ........ Indicates the Control Panel Key Lock is enabled.
Thermometer symbol
... Indicates the lamp mode is forcibly set to Eco mode
because the internal temperature is too high.
Menu Elements
Title
Slide bar
Highlight
Radio button
Check mark Solid triangle
Tab
Source
Key symbol
Thermometer symbol
To Next Page
