Necchi Q421A - Inserting the Bobbin

10
Inserting the bobbin
n
Attention
Turn the power switch to off ("O").
When inserting or removing the bobbin, the
needle and the presser foot must be fully
raised.
Open the bobbin cover by pushing the release
button to the right.
1
Release button
Insert the bobbin in the bobbin case with
the thread running in a counter-clockwise
direction (arrow).
Pull the thread through the slit (A).
:LWKD¿QJHUKROGJHQWO\RQWRSRIWKHEREELQ
please follow the arrow markings and draw
the thread into the bobbin thread guide from
(A) to (B).
Follow the arrow markings and draw the
thread into the bobbin thread guide from (B)
to (C).
To cut off excessive thread, pull it to the cutter
at point (C).
Close the bobbin cover.
1
