Nectar move NECFL03 - Headboard and Platform Setup

10
Assembling the headboard bracket (oponal)
IMPORTANT!
• Failure to follow the installaon steps as they appear in this guide could result in damage to your adjustable
bed.
• For safe reasons, liing of the adjustable bed must always be performed by two (2) people; and the unit
should always be on a at surface.
• Make sure to posion the boom of the headboard cross member no more than 3 inches (76.2 mm)
between the headboard and the top of the maress.
1
Turn the bed frame unit over with the top side facing down.
Remove the leg at the head secon of the bed frame by turning
the leg counter-clockwise.
Slide the inner headboard bracket over the hole for the leg
aachment.
Thread the leg back in, turning clockwise. This will secure the
inner headboard bracket between the bed frame and the leg.
Place the open side of the outer headboard bracket onto the
exposed square tube of the inner headboard bracket to create
a ght t.
Insert a retainer bolt ed with a washer through the outer
headboard bracket and into the inner headboard bracket.
Tighten the bolt with an Allen key wrench. Leave loose enough
for adjusng.
Repeat steps 2 to 6 to install the brackets on the other side of
the head secon of the bed frame.
When the headboard brackets are assembled, make sure there
is a space of 1.5 inches (38.1 mm) to 2 inches (50.8 mm) between
the edge of the bed frame and the headboard brackets.
Securely fasten the headboard bolts (not included with your
parts box) to the end of the headboard bracket assembly.
Turn the bed frame over carefully with the topside facing up.
If you need to adjust the headboard brackets, unscrew the
bolts holding the outer headboard bracket and move them the
necessary distance. Reinstall the bolts and ghten securely.
2
3
4
5
6
7
8
9
10
11
Place your mattress on the adjustable bed surface.
Your adjustable bed and headboard installation is now
complete.
Installaon Guide
