Nedap Convexs Series User Manual

© Nedap N.V. Nedap Readers Installation Guide
Page 4 of 21
1. Nedap Readers General Information
The Nedap readers (e.g. Convexs or Invexs readers) enables smooth migration to Mifare card technology in both
existing Nedap XS and Nedap AEOS Enterprise systems. It is capable of reading both Nedap and Mifare cards.
The cards that are read are converted (and optionally filtered) to the selected output format.
The readers output (the data the Convexs or Invexs reader sends) can be set to either Wiegand, XS RF
modulation or RS485 protocol (encrypted for connection to AEOS or plain output).
Installation aspects and technical data of the Nedap readers can be found in their corresponding Installation
sheets (e.g. Convexs_InstallSheet_E)
With Mifare also the Mifare Ultralight card is included, DESFire included EV1 card (check firmware version).
1.1. Nedap readers principle
1.2. Availability Convexs 80 readers:
Surface mounted
Flush mounted
G
C
FG
FC
Credentials
Convexs M80xx
9856250 9895400 9856420 9895540 Mifare
Convexs MD80x
x
9856900 9895680 9857060 9895710 Mifare - DESFire
Convexs MN80xx
9856110 9895850 9856390 9895990 Mifare - Nedap
Convexs MND80xx
9896210 9896040 9896350 9896180 Mifare - Nedap – DESFire
G
ray
C
harcoal
F
lush,
G
ray
F
lush,
C
harcoal
Gray=Light, Charcoal=Dark
For both Surface mounting and flush mounting rugged Protectors are available, making the Convexs more vandal
resistant.
1.3. Availability Invexs 170 readers:
The Invexs can read Mifare, DESFire and Nedap cards, and is equipped with keypad and / or a display.
Following Invexs 170 readers are available (with white or black back plane, Screen / display only on request)
Colour Reader Keypad Screen / Display
M170
Mifare
Black M170B
9833900
MK170B
9834230
MKS170B
9939822
White M170W
9832750
MK170W
9832920
MKS170W
9833390
MD170
Mifare DESFire
Black MD170B
9834400
MDK170B
9834680
MDKS170B
9939849
White MD170W
9834370
MDK170W
9834540
MDKS170W
9891820
MN170
Mifare Nedap
Black MN170B 9834060 MNK170B 9833730 MNKS170B 9833870
White MN170W 9832890 MNK170W 9833080 MNKS170W 9833420
MND170
Mifare DESFire Nedap
Black MND170B
9899570
MNDK170B
9938761
MNDKS170B
9938796
White MND170W
9899430
MNDK170W
9938753
MNDKS170W
9938788
Outputs:
- Nedap RF data
- Nedap RF badge
- RS485 NR
- Wiegand
- Serial (RS485) plain
Card credentials
- Nedap
- Mifare
Nedap reader configuration
(Conversion settings and formats)
Flush mounting
Surface mounting
Protectors
1
2
3
4
5
6
7
8
9
C
0
E
