Nederman Customer Service & Technical Support techsupport.us@nederman.com +1 (336) 821-0800
22
105” (2667 mm)
Section 10.0 Data Sheets – S-1000
131” (3327 mm)
Optional Collectors:
• 45 gal (270 L) Barrel
• 230 gal (871 L) Collection Bin
33" W x 70.5" L x 36.5" H
(838 mm x 1790 mm x 927 mm)
Weight: 500 lbs. (227 kg)
50” (1270 mm)
Design Floor model for indoor use
Specifications Inlet hole size: 15.74” (400 mm)
Filter bag size:
8.66” (220 mm) x 77.16” (1960 mm)
Filter bag qty.: twenty-four (24)
Filter bag: Superbag 2000 XT15 Antistatic Polyester
Filter area per bag: 15.00 ft
2
(1.4 m
2
) Total Filter area: 360 ft
2
(33.45 m
2
)
Air flow capacity: 4,000-5,000 cfm (6796 – 8495 m
3
/hr)
Static pressure: wg = in of H
2
0 (PA)
8.0” (1993 Pa) @ 4,000 cfm (6796
m
3
/hr
)
7.0" (1744 Pa) @ 5,000 cfm (8495 m
3
/hr)
Dimensions Base: 50” (1270 mm) x 105“ (2667 mm)
Height: 131” (3327 mm)
Weight/Shipping weight: 1000-1060 lbs. (454-48 1kg) / 1160-1220 lbs. (526-553 kg)
Construction Collector: Pre-formed galvanized steel
Motor Type: TEFC capacitor-start induction
S
ize: 10 hp (7.5 kW)
Phase type/voltage: 3 phase 208-230/460 V or 3 phase 575 V
Frequency: 60 Hz
Speed: 1760 rpm
Activation: On/Off push button
Bearings: factory lubricated
