Page #3 background imageLoading...
Page #3 background image
Page 3 of 13
Important Safety Instructions
Caution:
Read these instructions:
Read and understand all safety and operating instructions before using the equipment.
Keep these Instructions:
The safety instructions should be kept for future reference.
Heed all Warnings:
Follow all warnings and instructions marked on the equipment or in the user information.
Avoid Attachments:
Do not use tools or attachments that are not recommended, because they may be hazardous
Warning!:
• This equipment should be operated only from the included power supply.
To remove power from the equipment safely, remove all power cords from the rear of the equipment, or the
desktop power module (if detachable), or from the power source receptacle (wall plug).
Power cords should be routed so that they are not likely to be stepped on or pinched by items placed upon or
against them.
Do not defeat the safety purpose of a polarized or grounding-type plug. A polarized plug has two blades with one
wider than the other. A grounding-type plug has two blades and a third grounding prong. The wide blade or the
third prong is provided for your safety. If the provided plug does not t into your outlet, consult an electrician for
replacement of the obsolete outlet.
• Unplug this apparatus during lightning storms or when unused for long periods of time.
Refer all servicing to qualied service personnel. There are no user-serviceable parts inside. To prevent the risk of
shock, do not attempt to service this equipment yourself because opening or removing covers may expose you to
dangerous voltage or other hazards. Contact your local Neets reseller or distributor.
If the equipment has slots or holes in the enclosure, these are provided to prevent overheating of sensitive
components inside. These openings must never be blocked by other objects.
• Do not use this equipment near water.
To reduce the risk of re or electric shock, do not expose this apparatus to rain or moisture and objects lled
with liquids.
Unplug the product before cleaning. Clean only with a dry cloth and not cleaning uid or aerosols. Such products
could enter the unit and cause damage, re, or electric shock. Some substances may also mar the nish of the
product.
FCC Class A Notice:
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part
15 of the FCC Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause undesired operation.
The Class A limits are designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference, in which case the user will be required to correct the interference at his own expense.
FCC regulations state that any unauthorized changes or modications to this equipment, not expressly approved by
the manufacturer, could void the user’s authority to operate this equipment.
The lightning bolt triangle is used to alert the user to the presence of uninsulated “dangerous
voltages” within the unit’s chassis that may be of sufcient magnitude to constitute a risk of electric
shock to humans.
The exclamation point triangle is used to alert the user to presence of important operating and
service instructions in the literature accompanying the product.
!

Other manuals for Neets echo plus

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Neets echo plus and is the answer not in the manual?

Neets echo plus Specifications

EcHo Plus EU

Power IconPower
input voltage12 VDC
power usage1 W
power adaptor input voltage100 VAC – 240 VAC
line frequency50 Hz – 60 Hz
max power usageMax 8 W
Ports & Interfaces IconPorts & Interfaces
RS-232 port count1 x bi-directional
RS-232 port baud rate1200 – 115200 bit/sec
RS-232 port data bits7, 8
RS-232 port parityEven, Odd, None
RS-232 port stop bits1, 2
RS-232 port connector3 pin screw block
RS-232 or IR port count1 x uni-directional
RS-232 or IR port baud rate1200 – 115200 bit/sec
RS-232 or IR port data bits7, 8
RS-232 or IR port parityEven, Odd, None
RS-232 or IR port stop bits1, 2
RS-232 or IR port IR frequency400 Hz to 500 KHz
RS-232 or IR port connector2 pin screw block
Network speed10 / 100 Mbit
Network duplex modesHalf or Full
Network DHCPDefault off
Network default IP192.168.254.252
Network default gateway192.168.1.1
Network default subnet mask255.255.255.0
Operating Environment IconOperating Environment
storage temperature-20 °C to 50 °C
operation temperature0 °C to 30 °C
storage moistureNon-condensing
operation moistureNon-condensing
Weight and Dimensions IconWeight and Dimensions
width55 mm
height55 mm
depth17 mm
weight90 g
shipping weight0.3 kg
shipping dimension155x85x55 mm

EcHo Plus DK

Power IconPower
input voltage12 VDC
power usage1 W
power adaptor input voltage100 VAC – 240 VAC
line frequency50 Hz – 60 Hz
max power usageMax 8 W
Ports & Interfaces IconPorts & Interfaces
RS-232 port count1 x bi-directional
RS-232 port baud rate1200 – 115200 bit/sec
RS-232 port data bits7, 8
RS-232 port parityEven, Odd, None
RS-232 port stop bits1, 2
RS-232 port connector3 pin screw block
RS-232 or IR port count1 x uni-directional
RS-232 or IR port baud rate1200 – 115200 bit/sec
RS-232 or IR port data bits7, 8
RS-232 or IR port parityEven, Odd, None
RS-232 or IR port stop bits1, 2
RS-232 or IR port IR frequency400 Hz to 500 KHz
RS-232 or IR port connector2 pin screw block
Network speed10 / 100 Mbit
Network duplex modesHalf or Full
Network DHCPDefault off
Network default IP192.168.254.252
Network default gateway192.168.1.1
Network default subnet mask255.255.255.0
Operating Environment IconOperating Environment
storage temperature-20 °C to 50 °C
operation temperature0 °C to 30 °C
storage moistureNon-condensing
operation moistureNon-condensing
Weight and Dimensions IconWeight and Dimensions
width45 mm
height72 mm
depth17 mm
weight90 g
shipping weight0.3 kg
shipping dimension155x85x55 mm

EcHo Plus US

Power IconPower
input voltage12 VDC
power usage1 W
power adaptor input voltage100 VAC – 240 VAC
line frequency50 Hz – 60 Hz
max power usageMax 8 W
Ports & Interfaces IconPorts & Interfaces
RS-232 port count1 x bi-directional
RS-232 port baud rate1200 – 115200 bit/sec
RS-232 port data bits7, 8
RS-232 port parityEven, Odd, None
RS-232 port stop bits1, 2
RS-232 port connector3 pin screw block
RS-232 or IR port count1 x uni-directional
RS-232 or IR port baud rate1200 – 115200 bit/sec
RS-232 or IR port data bits7, 8
RS-232 or IR port parityEven, Odd, None
RS-232 or IR port stop bits1, 2
RS-232 or IR port IR frequency400 Hz to 500 KHz
RS-232 or IR port connector2 pin screw block
Network speed10 / 100 Mbit
Network duplex modesHalf or Full
Network DHCPDefault off
Network default IP192.168.254.252
Network default gateway192.168.1.1
Network default subnet mask255.255.255.0
Operating Environment IconOperating Environment
storage temperature-20 °C to 50 °C
operation temperature0 °C to 30 °C
storage moistureNon-condensing
operation moistureNon-condensing
Weight and Dimensions IconWeight and Dimensions
width45 mm
height105 mm
depth24 mm
weight90 g
shipping weight0.3 kg
shipping dimension150x170x55 mm
