Neets echo plus Installation Manual

Page 10 of 13
Neets Control
EcHo Plus, DK
P/N#: 310-0252
LAN
GND
GND
I/O 1
I/O 2
I/O 3
PWR
NDA
NCL
GND
GND
TX-1
TX-2
RX-1
GND
12V
When used as single IR port:
Connect the IR emitter to
TX-2 (striped wire) and GND,
as shown above.
Use Neets IR-Emitter
When used as RS-232
transmit port: Connect the
device to TX-1 and GND, as
shown above.
When used as dual IR port:
Connect the IR 1 emitter to
TX-2 (striped wire) and black
wire on IR 1 emitter to IR 2
emitter (striped wire), and
black wire from IR 2 emitter
to GND, as shown above.
Use Neets IR-Emitter
NEB Keypad, DK
P/N: 310-0214
GND
NCL
NDA
PWR
GND
NCL
NDA
PWR
Connecon
Set jumper for
address selecon
See soware
PWR
NDA
NCL
GND
GND
ADR
Unit
This
Control
System
Max 20cm
Adress
RoHS
Neets Control
EcHo Plus, DK
P/N#: 310-0252
LAN
GND
GND
I/O 1
I/O 2
I/O 3
PWR
NDA
NCL
GND
GND TX-1
TX-2
RX-1
GND
12V
Neets Control
EcHo Plus, DK
P/N#: 310-0252
LAN
GND
GND
I/O 1
I/O 2
I/O 3
PWR
NDA
NCL
GND
GND
TX-1
TX-2
RX-1
GND
12V
Junction
RS-232/IR port
The RS-232/IR port is used for either one-way
RS232 or IR communication depending on the
setup made in Neets Project Designer.
Be aware that the port can’t be used as RS232
and IR port at the same time.
Connect the port as shown below.
NEB port
The EcHo Plus has a built-in NEB (Neets Ex-
tension Bus) which can be used to add 2 NEB
devices.
Connect your NEB devices as shown to this
port with a cable not exceeding 20 cm of
length. Use NEB extenders if distances above
20 cm between the units is needed. See the
Neets website for details on the NEB Extender.
Neets Control
EcHo Plus, DK
P/N#: 310-0252
LAN
GND
GND
I/O 1
I/O 2
I/O 3
PWR
NDA
NCL
GND
GND
TX-1
TX-2
RX-1
GND
12V
PIN 5 <-> GND
PIN 2 <-> Tx
Neets Control
EcHo Plus, DK
P/N#: 310-0252
LAN
GND
GND
I/O 1
I/O 2
I/O 3
PWR
NDA
NCL
GND
GND
TX-1
TX-2
RX-1
GND
12V

Neets echo plus Specifications
