Page 2 of 13
Foreword
The purpose of this document is to describe how to install and configure the Neets Control –
EcHo Plus, hereafter mentioned as EcHo Plus.
COPYRIGHT - All information contained in this manual is the intellectual property of and copyright-
ed material of Neets. All rights are reserved. You may not allow any third party access to content,
information or data in this manual without Neets’ express written consent.
CHANGES - Neets reserve the right to change the specification and functions of this product
without any notice. Check www.neets.dk for the latest updated version of this manual.
Questions, AFTER reading this manual, can be addressed to your local distributor or:
Neets A/S
Denmark
by E-Mail: Support@Neets.dk
or you may use our contact form at www.neets.dk
Revision list
This document (no: 310-0152-001-009) has the following revision changes:
Author: Date Description Pages Rev
MH: 29-05-2015 First release. All 1.00
MH: 09-07-2015 Removed prod. number on frontpage 1 2.00
What is in the box?
When you open the box it will contain the following items:
EcHo Plus, DK
1 x Neets Control - EcHo Plus
1 x 12V wall plug PSU
Terminal connectors
1 x Front cover
1 x Paper cover
Quick guide
EcHo Plus, EU
1 x Neets Control - EcHo Plus
1 x 12V wall plug PSU
Terminal connectors
1 x Front cover
1 x Paper cover
Metal plate
2 x screws for metal plate
Quick guide
EcHo Plus, US
1 x Neets Control - EcHo Plus
1 x 12V wall plug PSU
1 x Wall plate
Terminal connectors
1 x Front cover
1 x Paper cover
2 x #6-32 screws for mounting
in standard US one-gang
electrical wall box or mounting
bracket (“mud ring”)
2 x white headed #6-32
screws for wall plate xation
Quick guide

Table of Contents

Other manuals for Neets echo plus

Preview: User Manual
User Manual12 pages

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Neets echo plus and is the answer not in the manual?

Neets echo plus Specifications

EcHo Plus EU

Power IconPower
input voltage12 VDC
power usage1 W
power adaptor input voltage100 VAC – 240 VAC
line frequency50 Hz – 60 Hz
max power usageMax 8 W
Ports & Interfaces IconPorts & Interfaces
RS-232 port count1 x bi-directional
RS-232 port baud rate1200 – 115200 bit/sec
RS-232 port data bits7, 8
RS-232 port parityEven, Odd, None
RS-232 port stop bits1, 2
RS-232 port connector3 pin screw block
RS-232 or IR port count1 x uni-directional
RS-232 or IR port baud rate1200 – 115200 bit/sec
RS-232 or IR port data bits7, 8
RS-232 or IR port parityEven, Odd, None
RS-232 or IR port stop bits1, 2
RS-232 or IR port IR frequency400 Hz to 500 KHz
RS-232 or IR port connector2 pin screw block
Network speed10 / 100 Mbit
Network duplex modesHalf or Full
Network DHCPDefault off
Network default IP192.168.254.252
Network default gateway192.168.1.1
Network default subnet mask255.255.255.0
Operating Environment IconOperating Environment
storage temperature-20 °C to 50 °C
operation temperature0 °C to 30 °C
storage moistureNon-condensing
operation moistureNon-condensing
Weight and Dimensions IconWeight and Dimensions
width55 mm
height55 mm
depth17 mm
weight90 g
shipping weight0.3 kg
shipping dimension155x85x55 mm

EcHo Plus DK

Power IconPower
input voltage12 VDC
power usage1 W
power adaptor input voltage100 VAC – 240 VAC
line frequency50 Hz – 60 Hz
max power usageMax 8 W
Ports & Interfaces IconPorts & Interfaces
RS-232 port count1 x bi-directional
RS-232 port baud rate1200 – 115200 bit/sec
RS-232 port data bits7, 8
RS-232 port parityEven, Odd, None
RS-232 port stop bits1, 2
RS-232 port connector3 pin screw block
RS-232 or IR port count1 x uni-directional
RS-232 or IR port baud rate1200 – 115200 bit/sec
RS-232 or IR port data bits7, 8
RS-232 or IR port parityEven, Odd, None
RS-232 or IR port stop bits1, 2
RS-232 or IR port IR frequency400 Hz to 500 KHz
RS-232 or IR port connector2 pin screw block
Network speed10 / 100 Mbit
Network duplex modesHalf or Full
Network DHCPDefault off
Network default IP192.168.254.252
Network default gateway192.168.1.1
Network default subnet mask255.255.255.0
Operating Environment IconOperating Environment
storage temperature-20 °C to 50 °C
operation temperature0 °C to 30 °C
storage moistureNon-condensing
operation moistureNon-condensing
Weight and Dimensions IconWeight and Dimensions
width45 mm
height72 mm
depth17 mm
weight90 g
shipping weight0.3 kg
shipping dimension155x85x55 mm

EcHo Plus US

Power IconPower
input voltage12 VDC
power usage1 W
power adaptor input voltage100 VAC – 240 VAC
line frequency50 Hz – 60 Hz
max power usageMax 8 W
Ports & Interfaces IconPorts & Interfaces
RS-232 port count1 x bi-directional
RS-232 port baud rate1200 – 115200 bit/sec
RS-232 port data bits7, 8
RS-232 port parityEven, Odd, None
RS-232 port stop bits1, 2
RS-232 port connector3 pin screw block
RS-232 or IR port count1 x uni-directional
RS-232 or IR port baud rate1200 – 115200 bit/sec
RS-232 or IR port data bits7, 8
RS-232 or IR port parityEven, Odd, None
RS-232 or IR port stop bits1, 2
RS-232 or IR port IR frequency400 Hz to 500 KHz
RS-232 or IR port connector2 pin screw block
Network speed10 / 100 Mbit
Network duplex modesHalf or Full
Network DHCPDefault off
Network default IP192.168.254.252
Network default gateway192.168.1.1
Network default subnet mask255.255.255.0
Operating Environment IconOperating Environment
storage temperature-20 °C to 50 °C
operation temperature0 °C to 30 °C
storage moistureNon-condensing
operation moistureNon-condensing
Weight and Dimensions IconWeight and Dimensions
width45 mm
height105 mm
depth24 mm
weight90 g
shipping weight0.3 kg
shipping dimension150x170x55 mm
