The air nozzle must be aligned with the cutting port to blow off the carbonized material,
otherwise it will be ineffective.
When do you need air assist？
Air-assisted engraving or cutting should only be used for engraving or cutting that produces
more carbonized substances. Generally, for depth of engraving less than 1mm, and the
cutting of plywood less than 2mm air assist is not required. A small fan can be used to blow
off the smoke generated by the engraving. Air assist is not recommended when engraving
images, and adding air assist at this time will destroy image details.
What kind of air pump is suitable for cutting?
The main function of air assist is to blow off the carbonized material produced by cutting,
and the general oxygener and electromagnetic inflator have almost no meaning. only the
pressure of the oil pump and air compressor (0.4-1.5mPa) has the effect of blowing away
the carbonized material. but it should be noted that the air of the oil pump contains oil and
cannot be directly used for the air-assisted module of the closed cavity, otherwise the oil will
contaminate the lens, resulting in power drop or damage to the lens. The air pressure of the
air compressor can be used for a short time with the closed cavity, but when used for a long
time, the water-containing gas will contaminate the lens, cause the power to drop, and even
damage the lens.
Specification
Power density: 2400W/mm²
Focus size: 0.1x0.1mm
Radiator Size: 40.5 x 56 x 113 mm
Weight: 600g
Interface: PH2.0 4Pin + 2Pin（EX Power）
Drive Design: Built-in
Input: 24V 3A +
Optical Power: < 24W
Wavelength: 450nm
Laser Class: Class 4
Number of Diodes: 4
PWM Input: VPP(3.3-24V), Recommend 1KHz
Max Speed of the Fan: 10600 RPM (Double ball bearing)
