IMO-218 EN - Issue 8/202026
HOW TO ORDER
1. 2. 3. 4. 5. 6. 7. 8. 9. 10. 11. 12.
RNP 150 SR40 C A 1 G D / * (NIL) * (NIL) * (NIL)
1. Series
RNP Rack and pinion actuator
2. Cylinder size
150
040
050
063
080
090
100
110
125
150
175
200
250
300
350
3. Spring version
SR30 3.0 barg spring version
SR40 4.0 barg spring version
SR55 5.5 barg spring version
DN00 Double acting
4. Action
C Spring to close (90°)
A Spring to open (90°)
D Double acting (90°)
5. Material
A Aluminum + anodized
B Aluminum + epoxy paint
6. Pinion & piston material
1 Carbon steel pinion / aluminum piston
7. Temperature range
G -20 ...+80 °C
H -20 ...+125 °C
8. Shaft bore-key type
D According to ISO 5211 square drive
9. Break
/ Type code break to be left blank if no options specified
10. Options
* (NIL)
11. Special construction
* (NIL)
12. Version
* (NIL)
