Version: 5.0
20.01.2017
10
EN
INSTALLATION
• Take o the bracket from the alarm body.
• Hold the bracket on the installation position, mark installation hole of the bracket with a
pencil.
• Make two installation holes with an electric drill.
Make holes of 5mm diameter, place the two plastic plugs into hole.
• Attach the bracket into the plastic plugs and x tightly with the screws (3*25mm)
(refer to Diagram 3).
• Fit the alarm on the bracket and turn the alarm body clockwise, until matching well on
the bracket.
• Test smoke alarm using test button. The alarm will sound 3 short beeps – 1.5 seconds
pause, then repeat it until you release the button.
• If there is no sound, it indicates a defective alarm, you can refer to “Trouble shooting” for
solution.
• If you have any questions on installation, you can contact your retailer.
WARNING
To prevent injury, this unit must be securely attached to the ceiling in accordance
with the installation instructions.
Diagram 2
PEAK CEILING
Dead Air
1000 mm
500 mm
Anywhere
in this area
Not
in this area
Do not install
