Neopost PF-90 User Manual

Upper Fold Table Receptacle Location
Lower Fold Table Receptacle Location
Plug in Receptacle
Plug in Receptacle
Fig. 3b
Fig. 3a
4. Plug the fold table cables in to the receptacles on the
side frame (Fig. 3a & 3b).
5. Insert the telescoping extension tray into the end of the
outfeed conveyor (Fig. 4).
6. Insert the Multi-Sheet Feeder into the four slots located
on the top cover (Fig 5).
7. Make sure the power switch is in the “OFF” position.
Plug the power cord into the power inlet and the wall
outlet.
Fig. 4
Fig. 5
4 Slots
3
Telescoping extension tray
© 2009 Neopost USA Inc. All rights reserved.
