Apex Classic Setup and Programming Guide v2.2 Page 14
is restarted. This is not a limitation of the Apex, rather the DNS service running
on your home network.
CONFIGURE THE APEX WEB INTERFACE PORT NUMBER
(OPTIONAL)
The Apex Base Module Web Interface uses an industry standard port number of
80. In most cases, there is no need to change this port number. If the need
arises, use the following instructions to change the port number. The
AquaController Apex can be configured to use any port number up to port 9999.
To update the Port Number:
Apex Display: System – Net Setup – Http Port – use the up/down arrows
to select the appropriate number, when done, press OK.
Web Interface: Configuration – Network Setup – click in the HTTP port
(default 80) box and type the desired port number, press the Update
Network Settings button to save changes.
WARNING: If the Port number is changed, the new port number must be
appended to the end of the URL in the browser window. For example:
http://apex:8080 where 8080 is the port number configured on the Apex.
CONFIGURE THE APEX WEB INTERFACE ADMINISTRATOR
CREDENTIALS
The Apex Base Module Web Interface uses the default user credentials of “admin”
and “1234”. It is strongly suggested that these credentials be changed to
something you can remember to protect your system from unauthorized access.
To update the Administrator Login name:
Apex Display: System – Net Setup – Admin Login – use the up/down
arrows to change the character of the highlighted digit, use the left/right
arrows to select the digit to change, when done, press OK.
Web Interface: This option is not available from the Web Interface.
To update the Administrator Password:
Apex Display: System – Net Setup – Admin Password – use the up/down
arrows to change the character of the highlighted digit, use the left/right
arrows to select the digit to change, when done, press OK.
Web Interface: This option is not available from the Web Interface.
