9. Lighting
Glazed wall cabinets are supplied with tted downlights. The lights supplied are 12V MR11 down lights. When replacing bulbs
the rating should not exceed 35W. Connect the Suolk lighting to a dimmable switched circuit for the best result.
10. Drawer Removal & Adjustment
Suolk Kitchen drawers are supplied with double extension soft close Kingslide drawer runners that support up to 30Kgs.
These runners enable the removal of the drawer box via quick release red toggles found on the underside of each drawer at
the front corner. The drawer box can also be adjusted in height to ensure perfect running and correct gap between carcass and
drawer front.
Step. 1
Step. 2
Drawer Installation
Roll
Height Adjustment
Roll the gear to lift up the
drawer front.
Drawer removal
Open the drawer.
Press the red handles of the
locking devices underneath.
Place the drawer on the slides and close the drawer.
Then the locking devices will click and engage with
the slides automatically. Open the drawer completely,
check if the locking devices have engaged.
