The Base End Panel should be attached to cabinets at the end of a run where the carcass can be seen. The panel should be cut
to length (and width if necessary), positioned behind the frame of the cabinet and pinned, glued or screwed in place.
End Panel
1. Position, level and attach in the same way as base cabinets.
2. The front face of the cabinet can be placed 600-700mm from the wall depending on your worktop and kitchen design.
3. The cornice should be attached to the cabinets in the same way as for wall cabinets.
Full Height Cabinets
700
Diagram 5.
2160
Diagram 6.
4
