BASIC PARTS OF THE MACHINES
2
4
8. Instant product canister
9. Coffee beans canister with a bulkhead
10. Coffee grinder
11. Coffee brewer
12. Nozzle holder
13. Grounds container
14. Door switch and service key
15. Internal button (PROG)
16. Protection carter
17. Door lock
18. Mixing bowls
19. Mixer motors
16
12
9
10
18
19
17
14
8
15
13
11
1
2
3
4
1. Front panel
2. Selection Button
3. Espresso cup stand
4. Drip tray and grid
5
5. Electrical socket
6. Power switch
7. Water inlet
