Netafim SPINNET

28 UPSIDE-DOWN MICRO-EMITTERS HANDBOOK
MICRO-SPRINKLERS/EMITTERS ASSORTMENT
Particular case - distribution uniformity
Double distribution pipe, UD positon, emitters' height above surface: 1.8 m
As a full coverage system with SpinNet™ emitters
Area width (m) 8.0 9.0 10.0 11.0
Model
SpinNet™
FLT 200
SpinNet™
FLT 200
SpinNet™
LR 160
SpinNet™
LR 160
Distance
between
micro-sprinklers (m)
2.0 1.0 2.0 1.0
distribution pipes (m) 5.2 5.4 6.2 6.8
CU% 97 95 92 90
Working pressure (bar) 2.0 2.0 2.5 2.0
PR (mm/h) 23.3 41.3 18.6 29.5
% water in strip 68 73 65 67
As two parallel strips with SpinNet™ SD emitters
Strip width (m) 8.0 9.0 10.0 11.0 12.0
Model
SpinNet™ SD
FLT 160/070
SpinNet™ SD
FLT 160/070
SpinNet™ SD
FLT 160/070
SpinNet™ SD
LR 120/70
SpinNet™ SD
LR 120/70
Distance
between
micro-sprinklers (m)
0.8 0.8 0.8 0.8 0.6
distribution pipes (m) 5.2 5.2 5.2 7. 2 7. 2
CU% 97 97 97 96 97
Working pressure (bar) 2.0 2.0 2.0 2.0 2.0
PR (mm/h) 22.3 19.8 17.9 15.4 15.4
% water in strip 84 95 100 75 82
The layouts, distances, working pressures and heights-
above-surface presented in the tables above are solely for
demonstration purposes. There are countless additional
configurations for micro-emitter placement.
To acquire accurate distribution data for a specific crop, contact the pertinent Netafim™ technical team.
%CU ≥ 94% ≥ 89% and < 94% < 89%
Legend
