Fan module
3. Align the edges of the replacement fan module with the opening in the controller module, and then slide the
replacement fan module into the controller module.
Step 4: Reinstall the controller module
After you replace a component within the controller module, you must reinstall the
controller module in the system chassis and boot it.
1. Close the controller module cover and tighten the thumbscrew.
68
