NetApp DS224C User Manual

Steps
1. Put on antistatic protection.
2. Unpack the new fan module, and place it on a level surface near the shelf.
Save all packing material for use when returning the failed fan.
3. From the back of the disk shelf, look at the Attention LEDs to locate the fan module you need to remove.
You must replace the fan module that has its Attention LED on.
Item LED name State Description
Attention Solid amber The fan has a fault
4. Press the orange tab to release the fan module handle.
32

NetApp DS224C Specifications

General

Form Factor	2U
Drive Bays	24
Drive Type	2.5-inch SAS
Maximum Raw Capacity	368 TB
Connectivity	12 Gbps SAS
Power Supply	Redundant power supplies
Cooling	Redundant fans
Storage Type	HDD and SSD
Compatibility	NetApp FAS and AFF systems
