NetApp E Series Hardware Maintainence Manual

The image above is an example; the appearance of your HIC may differ.
5. Using a #1 Phillips screwdriver, attach the HIC faceplate you removed from the original controller canister
to the new controller canister with the two screws.
Step 3c: Install power supply
Install the power supply into the replacement controller canister.
Steps
1. Using both hands, support and align the edges of the power supply with the opening in the system chassis,
and then gently push the power supply into the chassis using the cam handle.
The power supplies are keyed and can only be installed one way.
Do not use excessive force when sliding the power supply into the system; you can damage
the connector.
24

NetApp E Series Specifications

General

Form Factor	2U, 4U
Drive Types	SSD
Host Interface	SAS, iSCSI, FC, IB
RAID Levels	RAID 0, 1, 5, 6, 10
Operating System Compatibility	Windows, Linux, VMware
Management Software	SANtricity
