NetApp E Series Hardware Maintainence Manual

Step 3d: Install DIMMs
Install the DIMMs into the new controller canister.
Steps
1. Hold the DIMM by the corners, and align it to the slot.
The notch among the pins on the DIMM should line up with the tab in the socket.
2. Insert the DIMM squarely into the slot.
25

NetApp E Series Specifications

General

Form Factor	2U, 4U
Drive Types	SSD
Host Interface	SAS, iSCSI, FC, IB
RAID Levels	RAID 0, 1, 5, 6, 10
Operating System Compatibility	Windows, Linux, VMware
Management Software	SANtricity
