c. Slide the cable chain's horizontal connector under the guide rail on the horizontal bracket and push it in as far as it will
go.
Attention: Risk of equipment malfunction — Make sure to slide the connector underneath the guide rail on the
bracket. If the connector rests on the top of the guide rail, problems might occur when the system runs.
d. Slide the vertical connector on the right cable chain into the vertical bracket.
e. Once you have reconnected both ends of the cable chain, carefully pull on the cable chain to verify that both connectors
are latched.
Attention: Risk of equipment malfunction — If the connectors are not latched, the cable chain might come loose
during drawer operation.
8.
Reinstall the right fan canister. If the drive tray is receiving power, confirm that the green LED on the back of the fan is now
on and that air is now coming out of the back.
9.
If the power to the drive tray is off, reapply power, as follows:
If you... Follow these steps...
Replaced a drive drawer in a
controller-drive tray
a. Turn on both power switches on the controller-drive tray.
b. Wait 10 minutes for the power-on process to complete.
c. Confirm that both fans come on and that the green LEDs on the back of the fans are
illuminated.
Replaced a drive drawer in an
expansion drive tray without Drawer
Loss Protection
a. Turn on both power switches on the drive tray.
b. Confirm that both fans come on and that the green LEDS on the back of the fans are
illuminated.
c. Wait two minutes before applying power to the controller-drive tray.
d. Turn on both power switches on the controller-drive tray.
e. Wait 10 minutes for the power-on process to complete.
f. Confirm that both fans come on and that the green LEDS on the back of the fans are
illuminated.
