Netatmo Thermostat User Manual

The boiler adapter should be placed
as far as possible from metallic items
(wiring, pipes, electrical grid…).
The boiler adapter can be afxed to the wall with the double-sided tape
or the screws provided.
Connect the Relay into the boiler
adapter.
Switch the power supply back on.
The Relay will blink white.
Note : If the Relay does not blink after turning the power back on, it is not power supplied.
Please check how the blue and brown wires are wired. Do not forget to switch off the power supply before
any intervention.
30 cm
1
2
3
Setting the Relay Testing the Relay
or

Netatmo Thermostat Specifications

General

Interface	RF
Product color	Translucent, White
Memory function	No
Wi-Fi frequency	2.4 GHz
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Smart thermostat	Yes
Security algorithms	WEP, WPA, WPA2-AES, WPA2-TKIP
Maximum indoor range	100 m
Units of measurement	°C
Temperature increment	0.5 °C
Temperature setpoint range	5 - 30 °C
Battery life	2 year(s)
Battery type	AAA
Power source	Battery
Maximum switching current	4 A
Maximum switching voltage	250 V
Number of batteries supported	3
Quantity	1
Cables included	USB
Mobile operating systems supported	Android 4.2, Android 4.2.1, Android 4.2.2, Android 4.3, Android 4.4, Android 5.0, Android 5.1, Android 6.0, Android 7.0, Android 7.1, Android 7.1.2, Android 8.0, Android 9.0, Windows Phone 8, Windows Phone 8.1, Windows Phone 9, iOS 10.0, iOS 11.0, iOS 11.4, iOS 12, iOS 9.0, iOS 9.1, iOS 9.2, iOS 9.3, iPadOS
Humidity sensor	-

Weight and Dimensions

Depth	22 mm
Width	83 mm
Weight	185 g
