NETGEAR AX4200 User Manual

Rear panel
The following figure shows the rear panel connectors and buttons.
1 2 4 5 63
Figure 3. Rear panel
The rear panel contains the following components:
1. Reset button. Pressing the Reset button resets the router.
If the Reset button is pressed for at least 10 seconds and the Power LED blinks, the
router returns to its factory settings.
2. USB 3.0 port. Use the USB 3.0 port to connect USB storage device.
3. Ethernet ports. Four Gigabit Ethernet RJ-45 LAN ports. Use these ports to connect
LAN devices to the router.
4. Internet port. One Gigabit Ethernet RJ-45 WAN port to connect the router to an
Internet modem such as a cable modem or DSL modem.
5. DC power connector. Connect the power adapter that came in the product package
to the DC power connector.
6. Power On/Off button. Press the Power On/Off button to provide power to the
router.
User Manual12Hardware Setup
Nighthawk AX5 5-Stream AX4200 WiFi Router

NETGEAR AX4200 Specifications

General

WiFi Technology	WiFi 6 (802.11ax)
WiFi Performance	AX4200
Number of Bands	Tri-Band
Combined Speed	4.2 Gbps
USB Ports	1 x USB 3.0
Antenna	6 internal antennas
MU-MIMO	Yes
OFDMA	Yes
Beamforming	Yes
Ethernet Ports	1 WAN + 4 LAN Gigabit Ethernet ports
Security	WPA3
Memory	512MB RAM and 256MB Flash
