Wireless Cable Voice Gateway Model CBVG834G Adminstrators User Manual
Managing Your Network 4-7
v1.0, February 2008
LAN IP Settings
The gateway is preconfigured to use private IP addresses on the LAN side, and to act as a DHCP
server. You can use the LAN IP Setup screen to configure LAN IP services such as the IP address
of the gateway and DHCP.
To configure the LAN IP:
1. Under the Advanced heading on the main menu, select LAN IP. The LAN IP screen displays.
2. Enter the following information:
• LAN IP Address. The LAN IP address that you want to assign to your gateway. The
default is 192.168.0.1.
• Subnet Mask. The subnet mask for your network IP address. The default is
255.255.255.0. (Unless you are implementing subnetting, use the default subnet mask.)
Note: If you change the LAN IP address of the gateway while connected through the
browser, you will be disconnected. You must then open a new connection to the
new IP address and log in again
Figure 4-6
