NETGEAR EAX20 Quick Start

NETGEAR, Inc.
350 East Plumeria Drive
San Jose, CA 95134, USA
© NETGEAR, Inc., NETGEAR and the NETGEAR Logo are trademarks of
NETGEAR, Inc. Any non‑NETGEAR trademarks are used for reference
purposes only.
NETGEAR INTERNATIONAL LTD
Floor 1, Building 3,
University Technology Centre
Curraheen Road, Cork,
T12EF21, Ireland
June 2020
Contents Overview
Extender
Power Adapter
(varies by region)
A
WPS Button
1
- Ethernet LED
B
Reset Button
2
- 5 GHz WiFi LED
C
Ethernet Ports
3
- 2.4 GHz WiFi LED
D
Power Connector
4
- Router Link LED
5
- WPS LED
6
- Power LED
D
A
B
1
2
3
4
5
6
C
DC
Reset 1 2 3 4
WPS
2.4 GHz
5 GHz
Support and Community
Visit netgear.com/support to get your questions
answered and access the latest downloads.
You can also check out our NETGEAR Community for
helpful advice at community.netgear.com.
Si ce produit est vendu au Canada, vous pouvez accéder
à ce document en français canadien à
https://www.netgear.com/support/download/.
(If this product is sold in Canada, you can access this
document in Canadian French at
https://www.netgear.com/support/download/.)
For regulatory compliance information including the EU
Declaration of Conformity, visit
https://www.netgear.com/about/regulatory/.
See the regulatory compliance document before
connecting the power supply.
For NETGEAR’s Privacy Policy, visit
https://www.netgear.com/about/privacy‑policy.
By using this device, you are agreeing to NETGEAR’s
Terms and Conditions at
https://www.netgear.com/about/terms‑and‑conditions.
If you do not agree, return the device to your place of
purchase within your return period.
Regulatory and Legal

NETGEAR EAX20 Specifications

General

Type	Network repeater
WPS push button	Yes
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum transfer distance	- m
Package type	Box
Package depth	290 mm
Package width	210 mm
Package height	110 mm
Package weight	990 g
Master (outer) case width	242 mm
Master (outer) case height	380 mm
Master (outer) case length	477 mm
Master (outer) case weight	5370 g
Quantity per master (outer) case	4 pc(s)
Modulation	1024-QAM
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Cabling technology	10/100/1000Base-T(X)
Security algorithms	128-bit AES, WPA-PSK
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n
Ethernet LAN (RJ-45) ports	4
Product color	Black

Weight and Dimensions

Depth	169.5 mm
Width	241.7 mm
Height	63.4 mm
Weight	504.5 g
