Contents Overview
Extender
Power Adapter
(varies by region)
A
WPS Button
1
- Ethernet LED
B
Reset Button
2
5 GHz
- 5 GHz WiFi LED
C
Ethernet Ports
3
2.4 GHz
- 2.4 GHz WiFi LED
D
Power Connector
4
- Link Rate LED
5
- WPS LED
6
- Power LED
D
A
B
1
2
3
4
5
6
C
DC
Reset 1 2 3 4
WPS
2.4 GHz
5 GHz

NETGEAR EAX20 Specifications

General

Type	Network repeater
WPS push button	Yes
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum transfer distance	- m
Package type	Box
Package depth	290 mm
Package width	210 mm
Package height	110 mm
Package weight	990 g
Master (outer) case width	242 mm
Master (outer) case height	380 mm
Master (outer) case length	477 mm
Master (outer) case weight	5370 g
Quantity per master (outer) case	4 pc(s)
Modulation	1024-QAM
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Cabling technology	10/100/1000Base-T(X)
Security algorithms	128-bit AES, WPA-PSK
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n
Ethernet LAN (RJ-45) ports	4
Product color	Black

Weight and Dimensions

Depth	169.5 mm
Width	241.7 mm
Height	63.4 mm
Weight	504.5 g
