NETGEAR EX3700 User Manual

Extender Network Settings
21
AC750 WiF Range Extender
The screen adjusts and displays two more radio buttons.
7. Select a radio button:
• Router-to-Extender in 2.4 GHz only and Extender-to-Device in 5 GHz only.
• Router to Extender in 5 GHz only and Extender-to-Device in 2.4 GHz only.
8. Click the Save button.
Your changes are saved.
View WiFi Settings
 To view the WiFi settings:
1. On a computer or WiFi device that is connected to the extender network, launch a web
browser
.
2. In the address field of your browser
, enter www.mywifiext.net.
3. When prompted, enter your email address and password.
4. Click the Menu icon
.
The extender menu displays.
5. Select Settings > W
iFi.

NETGEAR EX3700 Specifications

General

Type	-
Maximum transfer distance	- m
Windows operating systems supported	Yes
Power over Ethernet (PoE)	No
Product color	White
Antennas quantity	2
Wi-Fi standards	Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Security algorithms	WPS
Wi-Fi data rate (max)	750 Mbit/s
Ethernet LAN (RJ-45) ports	1
Package depth	178 mm
Package width	143 mm
Package height	99 mm
Package weight	310 g
Shipping (inner) case width	390 mm
Shipping (inner) case height	339 mm
Shipping (inner) case length	333 mm
Shipping (inner) case net weight	4550 g
Number of layers per pallet (air)	4 pc(s)
Number of layers per pallet (sea)	6 pc(s)
Number of cartons per pallet layer	9 pc(s)
Quantity per shipping (inner) case	12 pc(s)
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	67.17 mm
Width	55.17 mm
Height	39 mm
Weight	130 g
