NETGEAR EX6400 Quick Start

5
Use the Extender in Extender Mode
In extender mode, the extender repeats the signals from an existing WiFi
router or access point.
Set the Access Point/Extender switch, place the extender, supply
power, and connect it to your WiFi network.
Set the Access Point/Extender Switch
To use the extender in extender mode, set the Access Point/Extender
switch to Extender .
Place the Extender and Supply Power
1. Place your extender in the same room as your WiFi router.
Proximity to the WiFi router is required only during the initial setup
process.
2. Plug the extender into an electrical outlet.
Wait for the Power LED to light green. This might take up to
100 seconds. If the Power LED does not light, press the Power On/
Off button on the side of the extender.

NETGEAR EX6400 Specifications

General

Power plug	-
Ethernet LAN	Yes
Wi-Fi standards	Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Security algorithms	WEP, WPA, WPA2-PSK
Networking standards	IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Built-in power socket	No
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	1
Ethernet LAN interface type	Gigabit Ethernet
WLAN data transfer rates supported	1900 Mbit/s
Product color	White
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	81.4 mm
Width	161 mm
Height	44.5 mm
Weight	300 g
