NETGEAR EX6400 Quick Start

9
Note: Since your router and extended networks share the same WiFi
network name, only one WiFi network name is broadcast.
Connect With the NETGEAR Installation Assistant
1. Connect your WiFi-enabled computer or mobile device to the
extender using a wired Ethernet or WiFi connection:
• To connect with a wired Ethernet connection, use an Ethernet
cable to connect the Ethernet port on the extender to an
Ethernet port on your WiFi-enabled computer.
• To connect with WiFi, on your WiFi-enabled computer or mobile
device, open the WiFi connection manager and locate and
connect to the extender network called NETGEAR_EXT.
After the connection with your WiFi-enabled computer or mobile
device is established, the Client Link LED lights.
2. Launch a web browser and visit www.mywifiext.net.
The NETGEAR installation assistant displays.
3. Follow the prompts to connect your extender to your existing WiFi
network.

NETGEAR EX6400 Specifications

General

Power plug	-
Ethernet LAN	Yes
Wi-Fi standards	Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Security algorithms	WEP, WPA, WPA2-PSK
Networking standards	IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Built-in power socket	No
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	1
Ethernet LAN interface type	Gigabit Ethernet
WLAN data transfer rates supported	1900 Mbit/s
Product color	White
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	81.4 mm
Width	161 mm
Height	44.5 mm
Weight	300 g
