Table 1. LED descriptions (Continued)
DescriptionLED
• Solid white. A USB device is connected to the extender.
• Off. A USB is not connected to the extender.
USB LED
• Solid white. An Ethernet device is connected to an Ethernet port.
• Off. An Ethernet device is not connected to the extender.
Ethernet LED
Back Panel
The back panel of the extender provides ports, buttons, and a DC power connector.
Figure 3. Back panel
The back panel contains the following components:
