NETGEAR GS316P User Manual

6SHFLĬFDWLRQV
6SHFLĬFDWLRQ Description
Network interfaces 16 Gigabit Ethernet RJ-45 ports that support 1G, 100 M, and 10 M
16 PoE/PoE+ ports
Power adapter input Power adapter varies by region.
Power adapter output The switch supports three power adapters:
200W: 54V @ 3.7A
130W: 54V @ 2.4A
90W: 54V @ 1.66A
Max PoE budget The maximum budget for each power adapter is as follows:
200W: 183W PoE
130W: 115W PoE
90W: 76W PoE
Dimensions (W x D x H) 11.26 x 4.02 x 1.06 in. (286 x 102 x 27 mm)
Weight 1.94 lb (0.88 kg)
Operating temperature 32–104°F (0–40°C)
Operating humidity 10%–90% relative humidity, noncondensing
Compliance FCC class A, CB, CE class A, VCCI class A, RCM class A, KC, BSMI

NETGEAR GS316P Specifications

General

Switch type	Unmanaged
Quality of Service (QoS) support	Yes
Power connector	DC-in jack
Installed SFP modules quantity	-
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	16
10G support	No
Networking standards	IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
Jumbo frames	9216
Latency (1 Gbps)	3.7 µs
MAC address table	4000 entries
Packet buffer memory	1 MB
Packet forwarding rate (1 Gbps)	1448000 pps
Heat dissipation	437.42 BTU/h
Operating altitude	0 - 3000 m
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 90 %
Input current	2.4 A
DC input voltage	54 V
Power consumption (max)	127.9 W
Mean time between failures (MTBF)	2362192 h
Product color	Black
Housing material	Metal
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	102 mm
Width	286 mm
Height	27 mm
Weight	880 g
