8 | Chapter 1: Connecting to the Internet
Mobile Broadband 11n Wireless Router MBR1000 User Manual
Internet Port Solid green There is an Internet session.
Solid red No Internet connection.
Blinking green Data is being transmitted over the Internet connection.
Blinking green and red Traffic meter limit has been reached.
Off No Internet connection detected or device in bridge mode.
Wi-Fi Solid blue The Wi-Fi local port is initialized.
Blinking blue Data is being transmitted or received over the Wi-Fi link.
Off The wireless access point is turned off.
LAN Ports Solid green The local Ethernet ports have detected wired links with PCs.
Blinking Data is being transmitted or received.
Off No link is detected on these ports.
WAN Port Solid green The Ethernet WAN port has detected an active link.
Blinking Data is being transmitted or received.
Off No link is detected on these ports.
2G/3G Solid blue Indicates the router is in 3G+ coverage.
Solid green Indicates the router is in 2G coverage.
Off No mobile broadband coverage is detected.
Signal Quality Solid blue Excellent mobile broadband coverage detected.
Solid green Good mobile broadband coverage detected.
Solid amber Marginal mobile broadband coverage detected.
Off No mobile broadband coverage detected.
Table 1. Front Panel Button and LED Descriptions
Button/LED Activity Description
