To wall mount your router or satellite:
1. Locate the two mounting holes on the mounting bracket.
2. Mark the wall where you want to insert the provided anchors and screws, which must
be 2.5 in. (63 mm) apart.
3. Drill two mounting holes in the wall.
4. Insert the supplied anchors and screws into the wall and tighten the screws with a
No. 2 Phillips screwdriver, leaving about 0.25 in. (6 mm) of each screw protruding
from the wall.
Note: When the screws are placed correctly, the holes at the back of the mounting
bracket fit over the protruding screws, allowing you to slide the mounting bracket
downward until the tops of the slots are resting on the screws.
5.
Thread the power connector through the opening at the bottom of the mount base.
For the router, also thread the Ethernet cable through the opening in the mount
base.
User Manual14Overview
Orbi Pro WiFi 6 Mini Router SXR30 and Orbi Pro WiFi 6 Mini Satellite SXS30
