Reference Guide for the Model RT311 and RT314 Internet Access Gateway Routers
Using the Manager Interface for System Maintenance 9-3
Table 9-1 lists the commands used in the System Maintenance - Status menu.
Table 9-2 lists the fields for Menu 24.1 - System Maintenance Status. These fields are read-only
fields.
Table 9-1. System Maintenance Status
Command Field Name Description
Enter 1 Drop WAN Log out of PPPoE or RoadRunner session.
Enter 9 Reset counters Resets the counters.
[Esc] Exits the screen.
Table 9-2. System Maintenance Status Fields
Field Description
Statistics The statistics for the WAN and LAN ports. For each port, the screen displays:
Status The link status of the port.
TxPkts The number of packets transmitted on this port since reset or manual clear.
RxPkts The number of packets received on this port since reset or manual clear.
Cols The number of collisions on this port since reset or manual clear.
Tx B/s The current line utilization—percentage of current bandwidth used on this port.
Tx B/s The average line utilization —average CLU for this port.
Up Time The time elapsed since this port acquired link or logged in.
Address
information
For the WAN and LAN ports, the screen displays:
Ethernet
address
The Ethernet MAC address of the port.
IP address The IP address assigned to the port.
IP mask The IP subnet mask assigned to the port.
DHCP The DHCP status of the port (Client, Server, or None).
System up Time The time elapsed since the last power cycle or reset.
Name The name of your router, which you configured in Menu 1 - General Setup.
RAS S/W Version The version of the current router software.
