NETGEAR 54 Mbps Wireless PCI Adapter WG311 v3 User Manual
2-8
v3.0, February 2007
2. Save your settings in a Profile.
a. Click the Save Profile button.
All the configuration settings are saved in this profile.
b. Click Apply.
c. Click Close to exit the Smart Wizard, or Cancel to return to the previous settings.
3. Configure the PC network settings.
a. Configure each PC with either a static IP address or with the IPX protocol.
b. Restart the PCs.
4. Verify wireless connectivity between your peer devices.
Verify connectivity by using the Ping program:
a. On the Windows taskbar click the Start button, and then click Run.
b. Assuming the target PC is configured with 192.168.0.1 as its IP address, type
ping -t
192.168.0.1
and then click OK.
Note: For instructions on configuring static IP addresses, refer to the networking
tutorial on your NETGEAR 54 Mbps Wireless PCI Adapter WG311 v3
Resource CD.
Figure 2-6
