NETGEAR WN2500RP User Manual

Getting Started
11
Universal Dual Band WiFi Range Extender WN2500RP
Use NETGEAR Genie to Set Up the Extender
The Smart Wizard can help you set up your extender to connect to a wireless network. For
information about more configuration options, see Chapter 2, Extender Network Settings.
The Universal Dual Band WiFi Range Extender WN2500RP Installation Guide (included in
the package) explains how to install your extender. During installation, when you launch your
Internet browser, the Smart Wizard automatically displays.
 After installation, to use NETGEAR Genie again:
1. Log in to the extender.
Note: Once you begin using NETGEAR Genie, you have to complete all of
its steps before you can exit.
2. From the menu, select Setup Wizard
. The following screen displays:
This is the same Smart Wizard that displays during installation, as described in the
installation guide.
3. Either select a network from the list, or select the Manually input my wireless SSID radio
button and type the SSID.

NETGEAR WN2500RP Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi standards	802.11a, 802.11b, 802.11g
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Bandwidth	2.4 GHz
Rack mounting	No
Minimum system requirements	Microsoft Internet Explorer 5.0, Firefox 2.0, Safari 1.4, Google Chrome 11.0
Ethernet LAN (RJ-45) ports	4
DHCP client	-
Security algorithms	WEP, WPA, WPA2-PSK
Certification	CEC, RoHS, WEEE
Product color	Black
LED indicators	LAN, Link, Power, WLAN

Weight and Dimensions

Depth	153 mm
Width	223 mm
Height	31 mm
Weight	370 g
