NETGEAR XAV5601 Installation Guide

5
LEDs
The LEDS indicate the status of your Powerline adapter.
• Wh
en you plug in the adapter, the Power LED lights up and
turns green.
• T
he adapter is not active when no Ethernet link has occurred for
more than 10 minutes. The adapter enters power saving mode,
and the Power LED turns amber.
• T
he Ethernet LED lights up when you connect a powered-on
Ethernet device to at least one Ethernet port.
• T
he Powerline LED turns on when the adapter detects at least
one other compatible Powerline device.
The Pick A Plug diagnostic featur
e lets you pick the electrical
outlet with the strongest throughput, indicated by the color
displayed by the Powerline LED:
-
Green: Link rate > 80 Mbps (Best)
-
Amber: Link rate > 50 and < 80 Mbps (Better)
-
Red: Link rate < 50 Mbps (Good)

NETGEAR XAV5601 Specifications

General

Data and routing protocols	IEEE 802.3 (10BASE-T), IEEE 802.3u (100BASE-Tx) IEEE 802.3ab (1000BaseTx)
Security encryption type	128-bit AES
MAC addresses	64: number of nodes that can be added to a single network
Frequency band:	2 –80Mbps
Modulation type:	OFDM symbol modulation
AC input	100–125V~, 0.2A max in North America and 200–250V~, 0.2A max in other regions
Power consumption	Normal: 4.5W, Power saving mode: <0.5W
Operating temperature	0 to 40 C (32º to 104º F)
Operating humidity	10–90% maximum relative humidity, noncondensing
Storage humidity	5–95% maximum relative humidity, noncondensing
Electromagnetic emissions:	FCC Part 15 Class B; CE-EMC Class B; 3-home FCC Certificate
Safety agency approvals:	UL Listed (UL 60950-1:2nd Ed.) /cUL (CSA C22.2 No.60950-1-07 2nd Ed.); CE LVD; TUV CB, TUV GS
Bandwidth	5 00Mbps
Data transfer rate	U p to 200M bps with real throughput greater than 80Mbps
Compatibility	Not HomePlug v1.0 or HomePlug v1.0 Turbo compatible

Weight and Dimensions

Dimensions	114 x 55 x 32.5 mm (4.5 x 2.2 x 1.28 in.)
Weight	0.174 kg (0.38 lb)
