Netis WF2216 User Manual

netis Wireless N Range Extender Quick Installation Guide
3.Extender Setup
3.1Extender setup via WPS Button
You can setup extender in two ways: pressing WPS Button or via Web
Management Page. We strongly suggest you use WPS Button to setup
Wi-Fi extender, because it is very easy and quick to setup.
WF2216
Step 1: Hardware Connection.
Root Router
Notebook
Ipad
Mobilephone
1） Please make sure that your root router can connect to the
Internet successfully and its WPS feature is enabled.
2） Plug WF2216 to a standard electrical socket.
*Please place the WF2216 closely to your root router when you
setup extender via WPS Button. Also after you are successfully
connected, you can move your WF2216 to other areas.
Step 2: Press the WPS button on your root router.
WPS
WPS
WPS

Netis WF2216 Specifications

General

Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	150 Mbit/s
Ethernet WAN	Yes
SIM card slot	-
Security algorithms	64-bit WEP, 128-bit WEP, AES, SSID, TKIP, WPA-PSK, WPA2-PSK
Product type	Tabletop router
Product color	Black
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Certification	FCC, CE
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45)
Antennas quantity	1
Antenna gain level (max)	3 dBi
AC input voltage	100 - 240 V
Power source type	AC
3G	No
