Netis WF2216 User Manual

netis Wireless N Range Extender Quick Installation Guide
Step 2: Set the IP address of the wired network adapter on your
computer as “Automatic” or “DHCP”.
For Windows 8/7/Vista
1) Go to "Settings" (Win 8)/"Start" (Win 7/Vista)>"Control Panel".
2) Left-click on "Network and Internet">"Network and Sharing
Center">"Change adapter settings" (Win 8/7)/"Manage
network connections" (Win Vista).
3) Right-click on "Local Area Connection" and left-click on "Properties".
4) Double-click on "Internet Protocol Version 4 (TCP/IPv4)".
5) Select "Obtain an IP address automatically" and "Obtain DNS
server address automatically" then left-click on "OK".
http:// netisextender.net
For Windows XP/2000
1) Go to "Start">"Control Panel".
2) Left-click on "Network and Internet Connections">
"Network Connections".
3) Right-click on "Local Area Connection" and left-click on "Properties".
4) Double-click on "Internet Protocol (TCP/IP)".
5) Select "Obtain an IP address automatically" and "Obtain DNS
server address automatically" then left-click on "OK".
For MAC OS
1) Click on the"Apple"menu>"System Preferences".
2) Click on the "Network" icon.
3) Click on "Ethernet" in the left side box and click on "Advanced"
in the lower right corner.
4) In the top options, select "TCP/IP".
5) In the pull-down menu next to "Configure IPv4″ select "Using DHCP".
6) Click "OK" then "Apply".
Step3: Open your browser and type " http://192.168.1.1"
(Default Login Address) or "http://netisextender.net " in the address
field to visit router's web management page.
http://192.168.1.1

Netis WF2216 Specifications

General

Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	150 Mbit/s
Ethernet WAN	Yes
SIM card slot	-
Security algorithms	64-bit WEP, 128-bit WEP, AES, SSID, TKIP, WPA-PSK, WPA2-PSK
Product type	Tabletop router
Product color	Black
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Certification	FCC, CE
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45)
Antennas quantity	1
Antenna gain level (max)	3 dBi
AC input voltage	100 - 240 V
Power source type	AC
3G	No
