Netis WF2375 User Manual

1.Package Contents
Please make sure that the package contains above items, if any of the listed items are damaged
or missing, please contact your distributor.
OutdoorAPRo uter
netis Wireless High Power Outdoor AP Router
Quick Installation Guide
netis Wireless High Power Outdoor AP Router Quick Installation Guide
1
2.Hardware Connection
The following items should be found in your package:
PoE Injector Power Adapter Quick Installation Guide Mounting Tie x2 Slip-proof Pad x2
* This QIG is for all netis Wireless High Power Outdoor AP Router, including models- WF2322,
WF2375, WF2370, etc.
* The product model shown in this QIG is WF2322, as an example.
The outdoor AP work in pairs, and work best when they are face to face like below, please try
to adjust their direction and get the best singal:
Please put the slip-proof pads and mounting ties as below:
When device works in Client or WISP mode,
1. Connection Step
A) Remove the small cover of device.
B) Connect one end of the Ethernet cable into the WAN/LAN ( ) port of the device and the
other end to the PoE port of the PoE injector.
C) Connect the Power Adapter to DC-in port of the PoE injector and plug the other end to wall outlet.
D) Connect the Ethernet cable into LAN/WAN port of PoE injector and the other end to the Ethernet
port of the PC or AP/switch.
E) Re-place the small cover back to the device.

Netis WF2375 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Receiver sensitivity	-98 dBm
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	433 Mbit/s
WLAN data transfer rate (first band)	150 Mbit/s
Transmit power	20 dBmW
Antennas quantity	1
Antenna gain level (max)	11 dBi
Security algorithms	64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-PSK
USB port	No
Ethernet LAN (RJ-45) ports	2
Product type	Tabletop router
Product color	White
LED indicators	LAN, Power, WAN
Output current	0.5 A
Output voltage	24 V
Power source type	DC, PoE
Certification	FCC, CE
Storage temperature (T-T)	-30 - 80 °C
Operating temperature (T-T)	-30 - 70 °C
Operating relative humidity (H-H)	0 - 90 %
