Netis WF2375 User Manual

3. Configure the AP Router via Web Management Page
This device works in AP mode by default, so if you are intend to change the working mode or
any settings, please connect your computer to or Port of AP and set a static IP for
you computer as below steps:
3.1 Set a Static IP for PC
Manually set the IP address of the wired network adapter on your computer as below.
IP Address/ IPv4 Address: 192.168.1.x (1<x<255)
Subnet Mask: 255.255.255.0
Default Gateway/ Router: 192.168.1.1
For Windows 8/ 7/Vista
1) Go to “Settings” (for Windows 8)/“Start” (for Windows 7/Vista) > “Control Panel”.
2) Left-click on “Network and Internet” > “Network and Sharing Center” > “Change
adapter settings” (for Windows 8/ 7)/”Manage network connections” (for Windows Vista).
3) Right-click on “Local Area Connection” and left-click on “Properties”.
4) Double-click on “Internet Protocol Version 4 (TCP/IPv4)”.
5) Select “Use the following IP address” then left-click on “OK”.
For Windows XP/2000
1) Go to “Start” > “Control Panel”.
2) Left-click on “Network and Internet Connections” > “Network Connections”.
3) Right-click on “Local Area Connection” and left-click on “Properties”.
4) Double-click on “Internet Protocol (TCP/IP)”.
5) Select “Use the following IP address” then left-click on “OK”.
For MAC OS
1) Click on the “Apple” menu > “System Preferences”.
2) Click on the “Network” icon.
3) Click on “Ethernet” in the left side box and click on “Advanced” in the lower right corner.
4) In the top options, select “TCP/IP”.
5) In the pull-down menu next to “Configure IPv4” select “Manually”.
6) Fill in the “IPv4 Address/Subnet Mask/Router” parameters, and click “OK” then “Apply”.
4
netis Wireless High Power Outdoor AP Router Quick Installation Guide
2. The connection will be similar to the figure below after the above steps are finished.
connect to xDSL or
Cable modem/router
Ether net Cable
Main Electrical Supply
INDOOR
Power Cable
PoE Inj ector
POW ER
Internet
LAN/WAN
AP/AP Router

Netis WF2375 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Receiver sensitivity	-98 dBm
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	433 Mbit/s
WLAN data transfer rate (first band)	150 Mbit/s
Transmit power	20 dBmW
Antennas quantity	1
Antenna gain level (max)	11 dBi
Security algorithms	64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-PSK
USB port	No
Ethernet LAN (RJ-45) ports	2
Product type	Tabletop router
Product color	White
LED indicators	LAN, Power, WAN
Output current	0.5 A
Output voltage	24 V
Power source type	DC, PoE
Certification	FCC, CE
Storage temperature (T-T)	-30 - 80 °C
Operating temperature (T-T)	-30 - 70 °C
Operating relative humidity (H-H)	0 - 90 %
