Netis WF2375 User Manual

5
3.3 A dialog box will prompt as below, please enter User name and Password, both default values
are guest and click OK.
Note: The configuration includes “Internet settings” and “Wireless settings”, if you choose “AP”,
please go to Wireless Settings directly.
AP Router Mode:
Select the correct Connection Type.
PPPoE Select “PPPoE” when：
1. WF2322 is connected to a DSL or Cable pure modem.
2. Got username &password from ISP
.
3. Broadband connection is needed on PC when bypassing
WF2322.
Type in the Username &
Password provided by the
ISP.
DHCP Select “DHCP” when:
1. WF2322 is connected to a Cable/DSL modem router.
2. Internet works directly on PC when bypassing WF2322.
(Dynamic IP)
Static IP Select “Static IP
” when:
1. Got IP Address, Subnet Mask, Default Gateway, DNS
Server from ISP.
Type in all the IP Info.
netis Wireless High Power Outdoor AP Router Quick Installation Guide
3.2 Open your browser and type http://192.168.1.1 in the address field to visit router's web
management page.

Netis WF2375 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Receiver sensitivity	-98 dBm
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	433 Mbit/s
WLAN data transfer rate (first band)	150 Mbit/s
Transmit power	20 dBmW
Antennas quantity	1
Antenna gain level (max)	11 dBi
Security algorithms	64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-PSK
USB port	No
Ethernet LAN (RJ-45) ports	2
Product type	Tabletop router
Product color	White
LED indicators	LAN, Power, WAN
Output current	0.5 A
Output voltage	24 V
Power source type	DC, PoE
Certification	FCC, CE
Storage temperature (T-T)	-30 - 80 °C
Operating temperature (T-T)	-30 - 70 °C
Operating relative humidity (H-H)	0 - 90 %
