Netis WF2375 User Manual

WISP Mode :
Select target network and Connection Type.
1. Click “AP Scan” button to select your target network and click “Connect” button.
2. Type in the wireless security info of the target network.
3. Select connection type. (Please refer to “Internet Settings” →“AP Router Mode”)
6
Note: The DHCP Server will be disabled after switching to “AP” mode successfully, so you will have
to set a static IP address for your PC first if you need to login to the web-based management page again.
3.4 The web management page will display after login successfully. Select the language as you need
on the top box, default is in English.
Wireless Settings
Setup a wireless network name in “SSID” box, it is recommended to use WPA-PSK/WPA2-PSK for
“Security” and set a wireless network key in the “Password” box, then click “Save” button.
3.5 When you completed the configuration,please remember to change the settings on your computer
back to to 'obtain an IP address automatically' in the the same window as step 3.1.
netis Wireless High Power Outdoor AP Router Quick Installation Guide

Netis WF2375 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Receiver sensitivity	-98 dBm
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	433 Mbit/s
WLAN data transfer rate (first band)	150 Mbit/s
Transmit power	20 dBmW
Antennas quantity	1
Antenna gain level (max)	11 dBi
Security algorithms	64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-PSK
USB port	No
Ethernet LAN (RJ-45) ports	2
Product type	Tabletop router
Product color	White
LED indicators	LAN, Power, WAN
Output current	0.5 A
Output voltage	24 V
Power source type	DC, PoE
Certification	FCC, CE
Storage temperature (T-T)	-30 - 80 °C
Operating temperature (T-T)	-30 - 70 °C
Operating relative humidity (H-H)	0 - 90 %
