netis Wireless Dual Band Router Quick Installation Guide
2
3.Configure the Router via Web
Management Page
3.1. Set the IP address of the wired network adapter on your computer
asAutomatic or DHCP.
For Windows 8/ 7/Vista
1) Go to “Settings” (Win 8)/ “Start” (Win 7/Vista)> “Control Panel”.
2) Left-click on “Network and Internet”> Network and Sharing Center”> “Change
adapter settings (Win 8/7)/ “Manage network connections (Win Vista).
3) Right-click on “Local Area Connection and left-click on “Properties”.
4) Double-click on “Internet Protocol Version 4 (TCP/IPv4)”.
5) Select “Obtain an IP address automatically and “Obtain DNS server address
automatically then left-click on “OK”.
For Windows XP/2000
1) Go to “Start”> “Control Panel”.
2) Left-click on “Network and Internet Connections”> “Network Connections”.
3) Right-click on “Local Area Connection and left-click on “Properties”.
4) Double-click on “Internet Protocol (TCP/IP).
5) Select “Obtain an IP address automatically and “Obtain DNS server address
automaticallythen left-click on “OK”.
For MAC OS
1) Click on the “Apple” menu> “System Preferences”.
2) Click on the “Network” icon.
3) Click on “Ethernet in the left side box and click on “Advanced” in the lower right corner.
4) In the top options, select “TCP/IP.
5 )In the pull-down menu next to “Configure Ipv4”, select “Using DHCP.
6) Click OK then “Apply.
3.2. Open your browser and type 192.168.1.1 in the address field to visit
router's web management page.
192.168.1.1

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Netis WF2780 and is the answer not in the manual?

Netis WF2780 Specifications

General IconGeneral
ButtonWPS, Reset
Operating Temperature0°C~40°C
Storage Temperature-40°C~70°C
Operating Humidity10%~90% non-condensing
Storage Humidity5%~90% non-condensing
Wireless StandardsIEEE 802.11a/b/g/n/ac
Frequency Range2.4GHz - 2.4835GHz
Wireless SpeedUp to 867Mbps at 5GHz; Up to 300Mbps at 2.4GHz
Ports1x WAN, 4x LAN
InterfaceRJ45
Security64/128-bit WEP, WPA-PSK/WPA2-PSK
LED IndicatorWAN
