Netis WF2780 User Manual

netis Wireless Dual Band Router Quick Installation Guide
3
1) In “Quick Setup” page, select your Internet Connection Type.
If “DHCP (Cable Modem)” is selected, the router will automatically receive the IP
parameters from your ISP (Internet Service Provider).
If “Static IP” is selected, please enter the IP Address/Subnet Mask/Default
Gateway/DNS Servers given by your ISP.
If “PPPoE” is selected, please enter the Username and Password given
by your ISP.
2) Under Wireless Setup, configure your wireless network name (SSID) and
password.
3) Left-click on “Save” to make your settings take effect.
3. 3. Select the language as you need on the top box,default is in English.
Tip 1:
IP address: 192.168.1.1
2.4G default SSID: netis_2.4G_XXXXXX 5G default SSID: netis_5G_XXXXXX
Default wireless password: password
(XXXXXX: Last 6 digits of LAN MAC Address)
Tip 2:
You can click on button on the top for other Internet
connection types and further settings.

Netis WF2780 Specifications

General

Button	WPS, Reset
Operating Temperature	0°C~40°C
Storage Temperature	-40°C~70°C
Operating Humidity	10%~90% non-condensing
Storage Humidity	5%~90% non-condensing
Wireless Standards	IEEE 802.11a/b/g/n/ac
Frequency Range	2.4GHz - 2.4835GHz
Wireless Speed	Up to 867Mbps at 5GHz; Up to 300Mbps at 2.4GHz
Ports	1x WAN, 4x LAN
Interface	RJ45
Security	64/128-bit WEP, WPA-PSK/WPA2-PSK
LED Indicator	WAN
