Warning!
1. Do not discard the magnets and plastic rivets in the tank.
Otherwise, the dehumidifier cannot be started, or the machine
will not automatically stop working when the water tank is full,
and the condensed water will overflow and possibly cause
damage to your property.
2. If the water tank is dirty, please rinse it with clean water. Avoid
using detergents, steel wire balls, chemical dust removers,
diesel, benzene, etc. otherwise it can cause damage to the
tank which may result in leakage.
Continuous Drainage
1. Take out the PVC drainpipe and straighten it out.
2. Insert one end of the drainpipe into the drain outlet at the top
of the tank and connect the other end to where you want the
condensed water to go.
Drainage Pipe
Warning!
1. Do not block the drainage outlet or pipe. If blocked, the water
may overflow and leak.
2. Do not bend the drainpipe. The height of the drainpipe should
be lower than the drainage outlet.
3. The drainpipe must be firmly connected to the drainage outlet.
4. Do not submerge the end of the drainage pipe into water as
this may cause an ‘air lock in the pipe, resulting in an
unsmooth water flow and possible leakage.
