NeuraLabel Callisto - New BNB Installation

NeuraLabel Callisto Service Guide
12
Confidential – Not for Redistribution
13. Lift the BNB away from the frame and set it aside.
NEW BNB INSTALLATION
1. Unbox the BNB. Set aside the temporary spittoon.
2. Remove all the blue tape. Keep the orange packing material in place.
3. Lift the BNB by the support beam above the printhead and the cover for
the ink housing. Set the BNB on the front and back members of the frame.
