QUICK REFERENCE CARD – NEW HOLLAND CX COMBINES
Form 147074 Rev. E (E27025) Page 4 of 4
963/2042 Initial Set-up.
Field Peas
Soybeans
Average Cereal Crops Dry Conditions Wet Condition Dry Conditions Wet Condition
Sickle-Check daily that guards are
aligned. Clearance from hold down
to sickle 0.020” (0.5mm)
- - - -
2000B Reel Fore/ Aft-5
th
hole/frt.
Cam Arm-Y
Range Slot- P
Finger Pitch- L or M
Reel Clearance- 2” (50 mm)
Speed- +10% of ground speed
2
nd
from front
Y
Q
M
2” (50mm)
-
2
nd
from front.
Y
P
J
2” (50mm)
-
2
nd
from front
X
P
M
2” (50mm)
-
2
nd
from front.
X
P
M
2” (50mm)
-
Draper Speed- Dial position “4”.
Draper opening- 53.5” (1360 mm)
-
-
-
-
-
-
-
-
Guard Angle- 1.0” (25mm) of
threads showing on center link.
Poly Skids- None
-
Yes
-
Yes
-
Yes
Center link fully
retracted.
Yes
Gauge Wheels (if equipped)-
Most cereals require “position 2”
stubble height setting.
Note: Gauge wheels should be in
storage position for on the ground
cutting applications.
Storage Storage Storage Storage
Float- Adjust float to achieve 0” gap
at downstop pad. (Refer to 873
Operator’s Manual)
½” gap ½” gap ½” gap ½” gap
Y
53.5
(1360 mm)
963/2042
Storage position
for on ground
application
